* It can be used to dry, baking and heating.
* It can reduce the damage caused by explosion.
* Large size can contain large test sample.
Model | Test area size (cm) (D×W×H) | Test area Capacity | External Size (cm) (D×W×H) | Temperature Range | Temperature Fluctuation | Power |
LCS-1900 | 140×90×150 | 1900 L | 110×160×190 | Ambient temperature +10 ~ 300℃ | ±0.5℃ | 8Kw |
LCS-2900 | 150×120×160 | 2900 L | 120×190×200 | 10Kw | ||
LCS-3600 | 160×140×160 | 3600L | 130×210×200 | 12Kw |
Doorknob | Multi doorknobs and multi door hinges to avoid side walking when explosion. |
Structure | Integrated structure to avoid explosion |
Explosion-proof door | An explosion-proof pressure-release door on the top. The door opens to release pressure when explosion occurs |
Extinguisher | Foam fire extinguisher |
External Material | Printed Cold-rolled steel plate |
Test Area Material | SUS304 stainless steel |
Insulation Material | Super glass cotton |
Controller | LCD-Touch Screen intellectual temperature controller |
Operation mode | Programmable and Fix |
Program volume | 180 programs, each program has maximum 99 steps, each step has maximum 99 hours 59 minutes. Program can be linked or cycled. |
Interface | Test data can be downloaded to user’s USB |
Heater | Nickel-cadmium heater |
Temp. sensor | PT100 temperature sensor |
Safety protection | Overheat, leakage, overpressure, overload, shout circuit protector |
Other structure parts | diameter ф50mm or ф100mm test hole |
Power supply | 380V±10% or 220V±10% |
